270 degree landing interactive holographic cabinet advertising machine

270 degree landing interactive holographic cabinet advertising machine
270 degree landing interactive holographic cabinet advertising machine
Send Inquiry
Product Code : MH
Price And Quantity
  • Minimum Order Quantity
  • 100
  • Unit of Measure
  • Piece/Pieces
  • Price
  • 0.5-9999 USD ($)
  • Price Range
  • 1.00 - 9999.00 USD ($)
Product Specifications
  • Sealed Type
  • Packing seal
Product Description
Product Introduction>>Overview:The holographic phantom imaging system uses a mid-air imaging system that suspends three-dimensional images in the real scene of the cabinet. The holographic phantom imaging system consists of a cabinet, a beam splitter, and a video playback device. Based on the principle of spectroscopic imaging, a special process of constructing a three-dimensional model is performed on the real shot of the product, and then the captured product image or product 3D model image is superimposed into the scene. , constitutes a dynamic and static product display system. You don't need people to wear any polarized glasses, you can enjoy 3D phantom stereo display effects without any restraint, giving people a visual impact and a strong sense of depth.

Advantage:

  • Great attraction, good effect: strong visual effect, it is easier to attract customers  eyes and achieve unforgettable effects.
  • Differentiated marketing can be achieved: it helps to improve brand and product grades and achieve differentiated marketing.
  • Good visuals: Images suspended in the air are sometimes in front of you, giving you the feeling of being within reach.
  • The image has a strong three-dimensional effect: sometimes it will bring people,s vision to the distant starry sky, suddenly and suddenly, suddenly and suddenly, unpredictable

Features:

  • Card loop playback function: convert the completed holographic video into MP4, MPG and other formats into the U disk or SD card, plug in the machine, can be played cyclically or remotely.
  • Network version function: Convert the completed holographic video into MP4, WMV and other formats and distribute it to the car on the machine.
  • The interactive version of the computer: the tablet or touch display and the holographic device are combined by software to achieve the customer,s selective interactive display effect on the exhibit.

Specifications:

Model

HDH180480

HDH180490

HDH180500

HDH180550

HDH180580

HDH180600

Display

48  X 1

49 X 1

50 X 1

55 X 1

58 X 1

60X 1

Touch screen

18.5 ,21.5, 48, 49, 50, 55, 58, 60

Touch mode

infrared / capacitor

Material

Sheet Metal

Sheet Metal

Sheet Metal

Sheet Metal

Sheet Metal

Sheet Metal

Holographic glass

Gray glass/white glass

Gray glass/white glass

Gray glass/white glass

Gray glass/white glass

Gray glass/white glass

Gray glass/white glass

Showcase size

Customization

Customization

Customization

Customization

1395 X 840 X 1650

Customization

Voltage

AC110-240V

AC110-240V

AC110-240V

AC110-240V

AC110-240V

AC110-240V

Video format

MP4, AVI,DIV, MPG

MP4, AVI,DIV, MPG

MP4, AVI,DIV, MPG

MP4, AVI,DIV, MPG

MP4, AVI,DIV, MPG

MP4, AVI,DIV, MPG

Android input interface

USB X 2, RJ45, SD

USB X 2, RJ45, SD

USB X 2, RJ45, SD

USB X 2, RJ45, SD

USB X 2, RJ45, SD

USB X 2, RJ45, SD

Computer input interface

USB X 4, HDMI X 1VGA, RJ45

USB X 4, HDMI X 1VGA, RJ45

USB X 4, HDMI X 1VGA, RJ45

USB X 4, HDMI X 1VGA, RJ45

USB X 4, HDMI X 1VGA, RJ45

USB X 4, HDMI X 1VGA, RJ45

Operating temperature

0 degrees -45 degrees

0 degrees -45 degrees

0 degrees -45 degrees

0 degrees -45 degrees

0 degrees -45 degrees

0 degrees -45 degrees

Audio

Speaker 5W X 2

Speaker 5W X 2

Speaker 5W X 2

Speaker 5W X 2

Speaker5W X 2

Speaker 5W X 2

Resolution

1920 X 1080

1920 X 1080

1920 X 1080

1920 X 1080

1920 X 1080

1920 X 1080

Base

Optional

Optional

Optional

Optional

1395 X 840 X 800

Optional

Warranty

LCD screen, motherboard wire warranty for one year, glass and shell face to face inspection

Expedited delivery instructions

Large-size holographic equipment production cycle generally takes 15-20 working days

If you need to expedite, you need to charge an additional 5,000 yuan, the delivery cycle is shortened to 12 days, and the shortest one week can be shipped. (Please contact the manufacturer for details)

Basic parameters:

  • Brand: Haode
  • Style: interactive, customizable (desktop, landing)
  • Imaging surface; 180 degrees (single side)
  • Display: 49 inches
  • Display ratio: 16:9
  • Display area: 1073.78 (vertical) x604 (horizontal) mm
  • Resolution: 13840*2160
  • Pitch: 0.09321 (vertical) × 0.27963 (horizontal) mm
  • Horizontal frequency: 30 – 80KHZ
  • Vertical frequency: 50-70HZ
  • Number of colors: 16.77 million true colors
  • Lamp life: 50000 hours
  • Average brightness: 400cd/m 2
  • Contrast: 1200: 1
  • Viewing angle: Up and down: 176o around 176o
  • Color saturation: 72% Display Colors: 16.7M
  • Function: Optional (single version, Android version, computer version)
  • Interface: USB, SD, HDMI, VGA, network cable interface, audio and video output interface, etc. (interfaces are matched according to functions)
  • Body material: sheet metal, customizable (acrylic, aluminum alloy)
  • Voltage: 110-220V
  • Accessories: remote control, power cord, warranty card, manual, certificate
  • Packing: Super hard cardboard box, over pressure foam, solid wood frame
  • Warranty: Machine warranty for 1 year
  • Remarks: The size, style and color of the machine of the custom style should be communicated with the manufacturer

Host configuration parameters:

Stand-alone host motherboard industrial single board
Support format Video format (MP4/WMA)
Maximum code stream USB2.0device; 30Mbit/sec
Support U disk playback, external play box and computer equipment
Interface USB/HDMI
Android host motherboard RK3288
CPU quad core Cortex-A17+GPU Mail-T764, Up to 1.8G
Memory 2G DDR3 (up to 4G)
Built-in memory EMMC8G/16G/32G (optional) Label 16G
Operating system Android 6.0.1
Interface USB*2/RJ45 (network interface)/SD
Computer host CPU Intel (Intel) Celeron quad-core four threads 2.41G (integrated J1900) (10W)
Motherboard Professional Industrial Control Board J1900
Memory Kingston DDR3 1600 4G (low voltage version)
Hard disk 120G solid state
Graphics Card Integrated Graphics Intel HD Graphics 4400
Power supply integrated power supply (19V)
OPS interface board 80pin standard interface expansion board
Interface 12VDC/HDMI/VGA/USB*4/RJ45/MIC
Computer host CPU Intel (Intel) Core Duo four-threaded 3.7GHz (Core I3 4170) (55W)
Motherboard Professional Industrial Control Board B85 (replaceable CPU)
Memory Kingston DDR3 1600 4G (low voltage version)
Hard disk 120G solid state
Graphics Card Integrated Graphics Intel HD Graphics 4400
Power supply integrated power supply (19V)
Ops interface board 80pin standard interface expansion board
Interface 12VDC/HDMI/VGA/USB*4/RJ45/MIC



Computer host CPU Intel (Intel) Core Quad-core four-threaded 3.2GHz (Core I5 ​​4430) (84W)
Motherboard Professional Industrial Control Board B85 (replaceable CPU)
Memory Kingston DDR3 1600 4G (low voltage version)
Hard disk 120G solid state
Graphics Card Integrated Graphics Intel HD Graphics 4600
Power supply integrated power supply (19V)
OPS interface board 80pin standard interface expansion board
Interface 12VDC/HDMI/VGA/USB*4/RJ45/MIC

Touch screen parameters
Infrared touch screen parameters:

Integration method Seamless built-in, embedded Touch resolution 4096- 4096
Touch technology Infrared multi-touch technology, standard 10-point touch control Touch effective recognition 2.5mm
Writing style Finger, pen; or any other non-transparent object Computer response Automatic system identification
Response time 5ms way of communication Full speed USB2.0
positioning accuracy ±1.5mm

 Capacitive touch screen parameters:

Touch mode Finger or cap Touch points 10 O'Clock
Finger touch time  35,000,000 times Withstand pressure <10g
Touch force 10-60g Surface hardness 7H
storage temperature -15oC~40oC, <90%RH; 40oC~70oC, <60%RH Relative humidity 10%~90%RH at 40oC, no condensation
Response time <10ms Transmittance >85%
thickness 1.6mm/changeable glass thickness, (1.1mm) + TopITO Film (0.125mm) +Bottom ITO Film (0.125mm) Durability Touch 50,000,000 times in the same position to work properly
