CNC VERTICAL LATHE MACHINE CV6070E

CNC VERTICAL LATHE MACHINE CV6070E
CNC VERTICAL LATHE MACHINE CV6070E
Send Inquiry
Product Code : CV3250
Price And Quantity
  • Minimum Order Quantity
  • 1 Set
  • Price
  • 1-9999 USD ($)
  • Price Range
  • 1.00 - 9999.00 USD ($)
Product Specifications
  • Product Type
  • Induction Motor
Product Description

CV32-CV80 CNC Vertical Lathe series products with the advantages of contemporary, Mechanical and electro-hydraulic integrated structure. Machine with high speed, high torque, high rigidity and so on. Main external parts used in all domestic and foreign well-known brand products, with high reliability and high durability. The machine is economy, efficiency, energy saving, it is the first choice by a complex disk class, crustaceans and short-axis machining part, the machine can finish a variety of threads, circular and rotary inside and outside the body surface, face, groove parts processing.

Main technical parameter:

Item Unit

Model

CV3250 CV5060 CV6070 CV8080
Working capacity Max. swing diameterMax. turning diameterMax. height of workpiece mm

mm

mm

500

450

500

700

600

600

800

700

700

1000800800
 Spindle  Speed rangeChuck diameterSpindle nose typeSpindle bearing(front) r/min

mm

mm

50-2000

12”(305

)A2-8180

20-1500

15”(380)

A2-11260

20-1000 21 (530)A2-11260 20-80024”(610)A2-11260
X/Z    X axis travelZ axis travelX axis rapid movingZ axis rapid moving mm

mm

m/min

m/min

-40ï¼›+250

500

20

20

-40;+350

600

15

15

-40;+500

800

15

15

-40+550

800

10(box-way type)10(box-way type)

Spindle motor (rated/30min)X axis servo motorZ axis servo motor kwN.mN.m AC221515 AC301818 AC371818 AC372222
 tool holder  Tool holder type Cylindrical cutter sizeBoring cutter Size   mmmm horizontal 8 station32X3240 horizontal 8 station32X3250 horizontal8 station32X3250 horizontal8 station32X3250
 Accuracy   Processing accuracyX/Z position accuracyX/Z repeat position accuracy     IT6-IT70.018/0.020.0075/0.015 IT6-IT70.018/0.020.0075/0.015 IT6-IT70.018/0.020.0075/0.015 IT6-IT70.018/0.020.0075/0.015
Overall dimensions mm 2900X1850X2950 3500X3500X3250 4000X4000X3450 4000X4000X3500
Weight  Machine weight kg 6200 8900 11800 13800
System CNC device model   SIEMENS828D/FANUC OiTF (be optional by customer

Trade Information
  • Supply Ability
  • 1000 Set Per Month
  • Delivery Time
  • 20-30 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
