Economic Round Pipe Cutting Machine
Brief Introduction
Portable CNC plasma cutting machine. Available for cutting any complex plane graphics, support for flame and plasma cutting; A substitute for manual torch, semi-automatic cutting machine and profiling cutting machine as an upgraded product; especially suitable for high-precision required complex graphics mass production, can greatly improve cutting efficiency, reduce secondary processing, and decrease the production cost.
Parameter
Model | Simply CNC Pipe Cutting Machine |
Cutting range | length: 6Msuitable for thickness 10mm |
Machine size | 6800*1600*1800 |
Cutting method | Flame/Plasma |
Cutting thickness | Flame cutting: 6-60mm Plasma cutting: according to plasma power |
Plasma cutting speed | According to plasma power |
Control system | F2300B |
Plasma cutting speed | 500-3500mm/min |
Plasma torch anti-collision protection system | Yes |
Driving method | Servo |
Software | PIPE2012 |
Working condition | |
Working pressure of compressed gas | 7Mpa |
Required gas flow of plasma | 4500L/H |
Working environment | Ventilation, no concussion |
Power voltage | 5KW(not include plasma power) |
Types of gas | Acetylene Propane |
![]() |
